Description
SPECIFICATIONS
- Max Tire Size: 35 x 12
- Front Lift Height: 5″
- Rear Lift Height: 3″
IMPORTANT NOTES
2015-2018 Models Only: 20″ wheels can not be reinstalled due to GM changing the wheel thickness. The ID of the 20″ wheels are smaller on 2015-2018 models.
Fitment: WILL fit RWD models, however the front differential related parts in kit will not be used.
Frame bracket modifications required for installation.
Mod’s Required: Modifications required for installation. See installation instructions for more information.
Optional steering stabilizer (PN# 7103) only fits vehicles that came equipped with a steering stabilizer from the factory.
Stock 17″ or 18″ Wheels cannot be re-installed.
Stock 20″ wheels cannot be reinstalled on 2015-2018 models.
Two-piece rear drive shaft? Add a carrier bearing drop kit to reduce post-lift driveline angles and avoid / eliminate driveshaft vibration.
Will fit RWD models. The front differential related parts will not be used.
With a 20″ Wheel, 5″-6″ backspacing is recommended.
In some cases vehicles used in 4WD on the highway regularly could potentially experience a minor front driveline vibration. If this occurs we recommend replacing the front driveshaft with a dual cardan style driveshaft.
INSTALLATION
Installation Guide: Download
Estimated Time: 7 hours
Difficulty Level: Medium-Hard
REQUIRED TOOLS
Torsion Bar Unloading Tool
